Bio-Safe System

GridSquare® Bio-Safe provides excellent hygiene and resistance to disinfectants. Its antimicrobial performance is an ideal solution for healthcare environments. It is the best solution for hospitals, laboratories and classroom spaces where you need cleanable surfaces.

Specifications (As per DSR)

GI Steel Sheet
Precoated (15 microns)/Powder coated (60 microns)

Standard Size	Thickness
600 x 600mm	15/16/19 mm
600 x 1200mm	15/16/19 mm

* Other dimensions available on request.

Edges	: Square / Tegular
Fire resistance	: BS 476 (Part 6 & 7)
NRC- Sound Absorption	: 0.20
Thermal Conductivity	: 0.052- 0.057 w/m K
Sound Attenuation Class (CAC)	: 38db
Humidity Resistance Max	: 95% RH
Finish	: Plain (for better cleaning)

Technical Specifications

Features

• Antimicrobial Performance
• Excellent Hygiene
• Antifungal
• Humidity Restance
• Fire Resistance

Advantages

• Plain washable Surface
• Fungicide treatment in the core to enhance the resistance to growth of micro-organisms.
• High light reflectance performance 86%
• High humidity resistant

Applications

• Hospitals
• Laboratries
• Classroom Spaces
• Operation Theatre
• ICU'S
• Pharmaceutical
